Magnecor 8mm Spark Plug Leads - Ignition Leads Mitsubishi Lancer EVO 4 5 6 7 8 9 CN9A CP9A CT9A Magnecor 8mm Spark Plug Leads 10 Year Guarantee Cable Specification HERE For Exploded Diagram Click HERE Mitsubishi Part Number MD321269 MD321270 MD343245 EVO 4 5 6 MD321269 EVO 7 8 MD321270 EVO 7 8 1822A013 EVO 9 1822A014 EVO 9
4 x NGK Platinum Spark Plugs for your Mitsubishi Lancer Evolution 4 CN9A One of the best spark plugs money can buy. Manufacturers Part Number PGR7A NGK Stock Number 4984 Plug Diameter 14mm Thread Length 19mm Hex Nut 20.8mm Heat Range 7 Laser Platinum® spark plugs provide high ignitability and longer service life. Dual platinum surfaces ensure slow wear rate providing stable idle, superior anti fouling, improved fuel efficiency and lower emissions. See HERE for PDF regarding NGK Plugs.
Magnecor 8.5mm Spark Plug Leads - Ignition Leads Mitsubishi Lancer EVO 4 5 6 7 8 9 CN9A CP9A CT9A Magnecor 8.5mm Spark Plug Leads 10 Year Guarantee Cable Specification HERE For Exploded Diagram Click HERE Mitsubishi Part Number MD321269 MD321270 MD343245 EVO 4 5 6 MD321269 EVO 7 8 MD321270 EVO 7 8 1822A013 EVO 9 1822A014 EVO 9
Water Pump Kit - Mitsubishi Lancer Evolution 4 CN9A 3 part kit consisting of Water Pump, Water Pump Gasket & Water Rail O'Ring Exploded Diagram HERE Mitsubishi Part Number MD977311 MD978552 MD975913 MD975644 1300A069
Crank Angle Sensor - Mitsubishi Lancer Evolution 4 CN9A
Choose from Aftermarket or Genuine Mitsubishi Exploded Diagram HERE Mitsubishi Part Number MD320754
Ignition coil pack - Mitsubishi Lancer Evolution 4 CN9A Choose from OEM Item or WVE from USA aftermarket copy. Exploded Diagram HERE Mitsubishi Part Number MD363552
Genuine Mitsubishi Head Gasket - Lancer EVO 4 CN9A Standard replacement Layered Steel Head gasket Mitsubishi Part Number MD333379 now MD346741
Water Pump Pulley - Mitsubishi Lancer EVO 456 CN9A CP9A
This is the pulley from the later EVO's which is made from thicker material and is cheaper!
Mitsubishi Part Number MD335066 now use MN143303
Lambda Sensor - Oxygen Sensor - Mitsubishi Lancer Evolution 4 CN9A Fits into turbo elbow shown HERE Aftermarket Copy ONLY as Mitsubishi have Discontinued Production - Sorry The aftermarket copy will need to be wired in but it's only 2 wires. It does not come with the connector. Wire Length is approx 750mm so plenty to work with. Mitsubishi Part Number MD319021 MD336486
LH Engine Mount/Gearbox Mount for Mitsubishi Lancer EVO 4 5 6 CN9A CP9A
Location Fitted Shown HERE
This part is Discontinued by Mitsubishi and is only available as a Roadnutz Aftermarket Part. Mitsubishi retail was way over £300. This not just the rubber part it's the whole mount.
Mitsubishi Part Number MR197547
Engine Spark Plug Plastic Cover - Mitsubishi Lancer Evolution 4 CN9A EVO 4 uses 2 different part numbers BUT Part Number MD345219 is now discontinued ie Mitsubishi no Longer Supply it. Exploded Diagram HERE Mitsubishi Part Number MD345681
Bottom Toothed Oil Pump Sprocket - Oil Pump Drive Sprocket Mitsubishi Lancer Evolution 4 CN9A Exploded Diagram Showing Location HERE Mitsubishi Part Number MD135005 MD124762
Knock Sensor - Detonation Sensor - Mitsubishi Lancer Evolution 4 CN9A Location Diagram HERE Mitsubishi Part Number MD197065 DISCONTINUED- NO LONGER SUPPLIED BY MITSUBISHI
Idle Speed Controller - Stepper Motor - EVO 4 CN9A If your engine idling is going up and down like a fiddlers elbow then this could well be the reason.
Supplied as an aftermarket Copy 2-3 Days or Genuine Mitsubishi (2-3 weeks) For an Exploded Diagram of inlet manifold and Throttle body Click HERE Mitsubishi Part Number MD614921
Piston Ring Set - Mitsubishi Lancer Evolution 4 CN9A Standard size piston ring set. Choose from Aftermarket or Genuine Mitsubishi set of piston rings Mitsubishi Part Numbers MD313405 Standard Size
Front Engine Mount to fit Mitsubishi Lancer Evolution 4 RS CN9A without ABS The one that sits at the front on the engine cradle If the engine rocks front to rear this is one of 2 mounts that may need changing. Exploded Diagram HERE Mitsubishi Part Number MR333022
DISCONTINUED - NO LONGER SUPPLIED BY MITSUBISHI
Hydraulic Cambelt Tensioner - Mitsubishi Lancer EVO 4 CN9A See exploded diagram HERE Mitsubishi Part Number MD308086
RoadNutz Lash Adjusters/Hydraulic Tappets x 16 for Lancer EVO 4 CN9A Full Set of 16 These are the later type with 3mm oil hole. Tappets are pre oiled ready for installation. Exploded Diagram HERE These are quality manufactured parts unlike some of our competitors We buy in the 1000's to get the best possible price. We then inspect each and every one for correct operation, hole size & burrs/poor finish. If any defects are found the tappet is discarded. Tappet Info & Bleeding Instructions HERE & HERE Mitsubishi Part Numbers for Ref: MD124739 MD149309 MD337687 MD377054 85004200 2461039100 2461033050 EAN:- 84 27769 45510 0RoadNutz Part Number: RN-VM-56
Cambelt Tensioner Adjustment Tool - Mitsubishi Lancer Evolution 4 CN9A 4G63T Timing belt tensioner pulley adjusting tool. Makes the job a lot simpler.
Genuine Mitsubishi Item
Mitsubishi Part Number MD998767 Now MD998767V (Was also MD998739)
Rear Engine Mount - Engine Roll Stop - Mitsubishi Lancer Evolution 4 CN9A GSR with ABS The one that sits at the rear on the engine cradle If the engine rocks front to rear this is one of 2 mounts that may need changing. See Exploded Diagram HERE Mitsubishi Part Number MR103555
Exhaust Manifold to Cylinder Head Studs, Nuts & Washers Kit - Mitsubishi Lancer EVO 4 5 6 CN9A CP9A Complete Set of All the studs, nuts & washers required to bolt the exhaust manifold to the cylinder head. ONE COMPLETE 27 PART KIT COMPRISING OF THE PART NUMBERS BELOW Mitsubishi Part Numbers MD005317 now MD031537 x7 MD041192 x7 MR212302 x7 MD146938 x2 MD050076 x2 MR224500 x2
Crank/Cam Pulley Removal Bolts - Mitsubishi Lancer Evolution 4 CN9A 4G63T These are used to help free off crank pulleys, cam pulleys etc by holding the pulley still while you undo the nut with a socket/spanner. They are used in conjunction with MB990767 or similar tool See HERE for Uses Mitsubishi Part Number MD998719
Front Engine Mount to fit Mitsubishi Lancer Evolution 4 GSR CN9A with ABS The one that sits at the front on the engine cradle If the engine rocks front to rear this is one of 2 mounts that may need changing. Exploded Diagram HERE Mitsubishi Part Number MR197540
Lower Cambelt Cover - Mitsubishi Lancer EVO 4 5 6 and 7 NOT EVO 8 or 9
Exploded Diagram HERE
Mitsubishi Part Number MD334395
Crank/Cam Pulley Removal Tool - Lever - Mitsubishi EVO 4 CN9A 4G63T This Lever to be Used in conjunction with MD998719 Uses HERE Mitsubishi Part Number MB990767
Middle Cambelt Cover - Mitsubishi Lancer EVO 4 5 6 and 7 NOT EVO 8 or 9
Mitsubishi Part Number MD334397
Gates Cambelt Kit - Mitsubishi Lancer Evolution 4 CN9A Complete Cambelt kit consisting of 1 x Gates Timing Belt 1 x Gates Balance Shaft Belt 1 x Cambelt Tensioner Bearing 1 x Upper Idler Bearing 1 x Balance Shaft Tensioner Bearing Gates Belts OE quality as it gets without the Dealer Pricetag Bearings are OE Manufacturers such as KOYO NTN NSK GMB Exploded Diagram Showing Locations these are fitted is HERE Mitsubishi Part Numbers MD326059 MD327394 VP326059 MD156604 MD182537 MD334548 MD369999 MD352473 MD115976 MD192068
