Alternator/Power Steering Belt - Without AC - Mitsubishi Lancer Evolution 4 CN9A Belt Layout HERE When you purchase a premium product like the Gates Micro-V® Belt, you know you’re making an investment in quality. By fitting a Gates Belt, you’re giving yourself peace of mind. To Put it Simply - The best belt money can buy. Mitsubishi Part Number MD340887
Engine coolant temperature sender, also called ECU Temp Sensor. This item can cause emissions problems if faulty. Check your old one using this guide HERE. THIS IMAGE shows location of this item Mitsubishi Part Numbers MD177572 MD182467 1308A012
Balance Shaft Belt Tensioner - Mitsubishi Lancer Evolution 4 CN9A 4G63T Koyo, NTN, GMB or NSK OEM suppliers Exploded Diagram HERE Mitsubishi Part Number MD352473 MD115976 MD192068
Extra Small GP0031 Small GP0032 Medium GP0033 Large GP0034 Extra Large GP0035
Oil Pump Gasket - MD322521 - Mitsubishi Lancer EVO 4 5 6 7 8 9
Large Oil Pump to Block Gasket
Mitsubishi Part Number MD322521
Balance Shaft Belt - Mitsubishi Lancer Evolution 4 CN9A 4G63T Choose from 2 different brands Gates or Mitsubishi OEM Exploded Diagram HERE Mitsubishi Part Number MR984778 MD182295
Rocker Cover Gasket - Mitsubishi Lancer Evolution 4 CN9A Exploded Diagram HERE Mitsubishi Part Number MD340535
Oil Seal Oil Pump Drive Gear Shaft - MD365697 - Mitsubishi Lancer EVO 4 5 6 7 8 9
Location used shown HERE
Mitsubishi Part Number MD365697 was MD095355
Banjo Bolt Oil Feed Pipe to Cylinder Head -Mitsubishi Lance EVO 4 5 6 also called a Turbo Eye Bolt - Size M10 x 20mm
Exploded Diagram Showing Location Fitted HERE
Mitsubishi Part Number MF650102
Crank Sensor Blade - Mitsubishi Lancer EVO 4 5 6 7 8 9
This is the Blade that the Crank Sensor uses to get it's signal
Exploded Diagram HERE
Mitsubishi Part Number 1840A006 was MD187953
Oil Seal Balance Shaft LH MD343565 - Mitsubishi Lancer EVO 456789
Fits into Oil Pump Housing
Location Shown HERE
Mitsubishi Part Number MD343565 was MD069950
Bolt - Crank Pulley to Crank - Mitsubishi Lancer EVO 4 CN9A Exploded Diagram HERE Mitsubishi Part Number 1101A022 was MD138069 MD074255 MD095201 MD131259
Upper Cambelt Timing Belt Idler Bearing Pulley - Mitsubishi Lancer Evolution 4 CN9A Koyo, NTN or NSK OEM suppliers The one attached to engine mount bracket See HERE Mitsubishi Part Number MD156604
Timing Belt Tensioner Bearing - Cambelt Tensioner Pulley - Mitsubishi Lancer Evolution 4 CN9A Exploded diagram showing Location HERE Mitsubishi Part Numbers MD182537 MD334548 MD369999
Valve Stem Seal Install Tool - Mitsubishi Lancer EVO 4 CN9A Aftermarket kit which can be used on various sizes.
Instruction sheet HERE Mitsubishi Part Number MD998737 Is Discontinued - Now Supplied as Aftermarket Kit
Oil filler cap for Mitsubishi Lancer Evolution IV CN9A The one on the rocker cover. Mitsubishi Part Number 1250A015 MD363392 MN143845 MD132260 MD317439
Big End Shells - Conrod Bearings - Mitsubishi EVO 4 CN9A Choose from 3 Different Genuine Mitsubishi Standard Sizes or aftermarket 0.25mm O/S or 0.5mm O/S Remember the Genuine Mitsubishi Bearings are sold individually ie you need to order 4 of them and the aftermarket standard & O/S ones are sold in full sets of 4 To help you choose the Genuine Mitsubishi bearings we have a link of the Full 4G6 engine manual HERE Size Diameter in mm S0 = 44.995-45.000 S1 = 44.985-44.995 S2 = 44.980-44.985 Mitsubishi Part Numbers S0 MD195939 MD326359 1115A429 S1 MD195940 MD326360 1115A430 S2 MD195941 MD326361 1115A431
Alternator/Power Steering Belt/Air Conditioning Belt - Mitsubishi Lancer Evolution 4 CN9A Belt Layout HERE When you purchase a premium product like the Gates Micro-V® Belt, you know you’re making an investment in quality. By fitting a Gates Belt, you’re giving yourself peace of mind. To Put it Simply - The best belt money can buy. Mitsubishi Part Number MD340886
Ignition Leads - Spark Plug Leads - Mitsubishi EVO 4 CN9A Good quality set of ignition leads wether you choose the OEM Set or the aftermarket set Exploded Diagram HERE Mitsubishi Part Number MD343245
Power Steering Idler Pulley - Mitsubishi Lancer Evolution 4 CN9A Exploded Diagram HERE showing location. Choose from Koyo Copy or Genuine Mitsubishi Part Remember Koyo made the Original for Mitsubishi Mitsubishi Part Number MD327654
Fuel Filler Cap - Mitsubishi Lancer EVO 4 CN9A
Choose from Original Mitsubishi or Aftermarket Lockable Exploded Diagram HERE Mitsubishi Part Number MN106160 MR271610 MB595538
Throttle Position Sensor - Mitsubishi Lancer EVO 4 5 6 CN9A CP9A
Aftermarket Copy as Mitsubishi want a small fortune for one. For an Exploded Diagram of inlet manifold and Throttle body Click HERE Mitsubishi Part Number MD614772
Cambelt Special Tools Fitting Kit - Mitsubishi Lancer Evolution 4 CN9A Complete kit of special tools for changing the cambelt on an EVO IV Made exclusively for Viamoto
Timing Belt/Cambelt for Mitsubishi Lancer Evolution 4 CN9A 4G63T Choose from Gates or Genuine Mitsubishi OEM Exploded Diagram HERE Mitsubishi Part Numbers MD326059 MD327394 VP326059
Cam Position Sensor - Mitsubishi Evolution 4 CN9A Choose from Aftermarket or Genuine Mitsubishi Exploded Diagram showing location HERE Mitsubishi Part Number MD327107 J5T23071A JT523071 J005T23071A
